TS-MNT-TOP-370 TS-MNT-TOP-370
Pipe Mounting KIT with shroud, capability of mounting 37cm diameter round antennas (with trident mounting bracket, max length 2.1m, max weight 56kg) on the top of a pole with diameter from Ø150 to Ø273mm
TS-MNT-TOP-370
  • Product type: Mounting kit
SpecificationsSpecs
TS-MNT-TOP-370
  • Product type: Mounting kit
UNA008R-V2 UNA008R-V2
1-port omni antenna, 694–896 MHz, 360° HPBW, 1x RET with manual override. Ships with F-129-S4 mounting kit.
UNA008R-V2
  • Product type: Omnidirectional antenna
  • Operating frequency band range: 575 – 960 MHz
  • Horizontal beamwidth: 360°
  • Length size: 2.5 m (8 ft)
  • Width/diameter: ≤ 200 mm
  • Rf connector interface: 7-16 DIN Female
  • Rf connector quantity, total: 1
  • Rf connector quantity, high band: 0
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 1
SpecificationsSpecs
UNA008R-V2
  • Product type: Omnidirectional antenna
  • Operating frequency band range: 575 – 960 MHz
  • Horizontal beamwidth: 360°
  • Length size: 2.5 m (8 ft)
  • Width/diameter: ≤ 200 mm
  • Rf connector interface: 7-16 DIN Female
  • Rf connector quantity, total: 1
  • Rf connector quantity, high band: 0
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 1
UNA010F-0-V2 UNA010F-0-V2
1-port omni antenna, 694–896 MHz, 360° HPBW, fixed tilt
UNA010F-0-V2
  • Product type: Omnidirectional antenna
  • Operating frequency band range: 575 – 960 MHz
  • Horizontal beamwidth: 360°
  • Length size: 2.5 m (8 ft) | 3.0 m (10 ft)+
  • Width/diameter: ≤ 200 mm
  • Rf connector interface: 7-16 DIN Female
  • Rf connector quantity, total: 1
  • Rf connector quantity, high band: 0
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 1
SpecificationsSpecs
UNA010F-0-V2
  • Product type: Omnidirectional antenna
  • Operating frequency band range: 575 – 960 MHz
  • Horizontal beamwidth: 360°
  • Length size: 2.5 m (8 ft) | 3.0 m (10 ft)+
  • Width/diameter: ≤ 200 mm
  • Rf connector interface: 7-16 DIN Female
  • Rf connector quantity, total: 1
  • Rf connector quantity, high band: 0
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 1
UNA010FI-0-V2 UNA010FI-0-V2
1-port inverted omni antenna, 694–896 MHz, 360° HPBW, fixed tilt
UNA010FI-0-V2
  • Product type: Omnidirectional antenna
  • Operating frequency band range: 575 – 960 MHz
  • Horizontal beamwidth: 360°
  • Length size: 2.5 m (8 ft) | 3.0 m (10 ft)+
  • Width/diameter: ≤ 200 mm
  • Rf connector interface: 7-16 DIN Female
  • Rf connector quantity, total: 1
  • Rf connector quantity, high band: 0
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 1
SpecificationsSpecs
UNA010FI-0-V2
  • Product type: Omnidirectional antenna
  • Operating frequency band range: 575 – 960 MHz
  • Horizontal beamwidth: 360°
  • Length size: 2.5 m (8 ft) | 3.0 m (10 ft)+
  • Width/diameter: ≤ 200 mm
  • Rf connector interface: 7-16 DIN Female
  • Rf connector quantity, total: 1
  • Rf connector quantity, high band: 0
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 1
UU-360S-F UU-360S-F
4-port small cell antenna, 4x 3300-5000 MHz. 360° Horizontal Beamwidth, fixed tilt.
UU-360S-F
  • Product type: Omnidirectional antenna | Small cell antenna
  • Operating frequency band range: 3100 – 5000 MHz
  • Horizontal beamwidth: 360°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: 201 – 305 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 4
  • Rf connector quantity, high band: 4
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 0
SpecificationsSpecs
UU-360S-F
  • Product type: Omnidirectional antenna | Small cell antenna
  • Operating frequency band range: 3100 – 5000 MHz
  • Horizontal beamwidth: 360°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: 201 – 305 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 4
  • Rf connector quantity, high band: 4
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 0
V17-001-01-A0-E V17-001-01-A0-E
Venue Antenna
V17-001-01-A0-E
  • Product type: Sector antenna | Stadium antenna
  • Operating frequency band range: 3100 – 5000 MHz
  • Horizontal beamwidth: < 25°
  • Length size: <0.7 m (2 ft)
  • Width/diameter: 201 – 305 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 2
SpecificationsSpecs
V17-001-01-A0-E
  • Product type: Sector antenna | Stadium antenna
  • Operating frequency band range: 3100 – 5000 MHz
  • Horizontal beamwidth: < 25°
  • Length size: <0.7 m (2 ft)
  • Width/diameter: 201 – 305 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 2
V360QS-C3-3XR V360QS-C3-3XR
2-port small cell antenna, 2x 1695–2690 MHz, 360° HPBW, 1x RET
V360QS-C3-3XR
  • Product type: Omnidirectional antenna | Small cell antenna
  • Operating frequency band range: 1427 – 2700 MHz
  • Horizontal beamwidth: 360°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: ≤ 200 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 2
  • Rf connector quantity, high band: 2
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 0
SpecificationsSpecs
V360QS-C3-3XR
  • Product type: Omnidirectional antenna | Small cell antenna
  • Operating frequency band range: 1427 – 2700 MHz
  • Horizontal beamwidth: 360°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: ≤ 200 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 2
  • Rf connector quantity, high band: 2
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 0
V37-001-01-A0-E V37-001-01-A0-E
2-port Venue Antenna, 3300-4000 MHz, 37° HPBW, Fixed Tilt
V37-001-01-A0-E
  • Product type: Sector antenna | Stadium antenna
  • Operating frequency band range: 3100 – 5000 MHz
  • Horizontal beamwidth: 33°
  • Length size: <0.7 m (2 ft)
  • Width/diameter: ≤ 200 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 2
SpecificationsSpecs
V37-001-01-A0-E
  • Product type: Sector antenna | Stadium antenna
  • Operating frequency band range: 3100 – 5000 MHz
  • Horizontal beamwidth: 33°
  • Length size: <0.7 m (2 ft)
  • Width/diameter: ≤ 200 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 2
V4-360S-F2 V4-360S-F2
8-port small cell antenna, 8x 1695–2690MHz, 360° Horizontal Beamwidth, fixed tilt.
V4-360S-F2
  • Product type: Omnidirectional antenna | Small cell antenna
  • Operating frequency band range: 1427 – 2700 MHz
  • Horizontal beamwidth: 360°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: 354 – 457 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 8
  • Rf connector quantity, high band: 8
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 0
SpecificationsSpecs
V4-360S-F2
  • Product type: Omnidirectional antenna | Small cell antenna
  • Operating frequency band range: 1427 – 2700 MHz
  • Horizontal beamwidth: 360°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: 354 – 457 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 8
  • Rf connector quantity, high band: 8
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 0
V4-65A-R4VB V4-65A-R4VB
8-port sector antenna, 8x 1695–2690 MHz, 65° HPBW, 4x RET
V4-65A-R4VB
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz
  • Horizontal beamwidth: 65°
  • Length size: 1.3 m (4 ft)
  • Width/diameter: 458 – 498 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 8
  • Rf connector quantity, high band: 0
  • Rf connector quantity, mid band: 8
  • Rf connector quantity, low band: 0
SpecificationsSpecs
V4-65A-R4VB
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz
  • Horizontal beamwidth: 65°
  • Length size: 1.3 m (4 ft)
  • Width/diameter: 458 – 498 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 8
  • Rf connector quantity, high band: 0
  • Rf connector quantity, mid band: 8
  • Rf connector quantity, low band: 0
V4S4-360S-BF2 V4S4-360S-BF2
16-port small cell antenna, 8x 1695-2690, 8x 3300-4000 MHz, 360° Horizontal Beamwidth, fixed tilt.
V4S4-360S-BF2
  • Product type: Beamforming antenna | Omnidirectional antenna | Small cell antenna
  • Operating frequency band range: 1427 – 2700 MHz | 3100 – 5000 MHz
  • Horizontal beamwidth: 360°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: 354 – 457 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 16
  • Rf connector quantity, high band: 8
  • Rf connector quantity, mid band: 8
  • Rf connector quantity, low band: 0
SpecificationsSpecs
V4S4-360S-BF2
  • Product type: Beamforming antenna | Omnidirectional antenna | Small cell antenna
  • Operating frequency band range: 1427 – 2700 MHz | 3100 – 5000 MHz
  • Horizontal beamwidth: 360°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: 354 – 457 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 16
  • Rf connector quantity, high band: 8
  • Rf connector quantity, mid band: 8
  • Rf connector quantity, low band: 0
V4S4-360S-F2 V4S4-360S-F2
16-port small cell antenna, 8x 1695-2690, 8x 3100-4200 MHz, 360° Horizontal Beamwidth, fixed tilt.
V4S4-360S-F2
  • Product type: Omnidirectional antenna | Small cell antenna
  • Operating frequency band range: 1427 – 2700 MHz | 3100 – 5000 MHz
  • Horizontal beamwidth: 360°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: 354 – 457 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 16
  • Rf connector quantity, high band: 16
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 0
SpecificationsSpecs
V4S4-360S-F2
  • Product type: Omnidirectional antenna | Small cell antenna
  • Operating frequency band range: 1427 – 2700 MHz | 3100 – 5000 MHz
  • Horizontal beamwidth: 360°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: 354 – 457 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 16
  • Rf connector quantity, high band: 16
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 0
